Description
Smaller, Lighter, and Faster—The Turbosmart TS-2 turbocharger series has been developed to leverage modern materials, design, and manufacturing techniques to create a Turbocharger range that meets the demands of motorsport and performance enthusiasts alike.
The TS-2 series is water and oil-cooled turbochargers with lightweight Investment cast turbine housings, a proprietary bearing and a central shaft combination that will provide the transient response you never knew possible with the type of performance, quality, reliability, and supply you’ve come to know Turbosmart for.
The ultra-low rotating mass of our unique bearing and shaft assembly is matched to aggressive compressor aerodynamics to ensure high-performance levels at lower shaft speeds. It is mated with a unique turbine wheel to provide power at high loads and maintain flow.
The TS-2 turbocharger series has taken an engine end-to-end approach aiming to achieve power through reduced back pressure and high-performance turbines – While being smaller, lighter and faster in response than other solutions on the market.
Available InTS-1 oil-cooled turbochargersTS-2 oil and water-cooled turbochargersV-Band, various T3 Flange and T4 Flange optionsReverse rotation (Selected Sizes)VarioAR’sR’s optionsInternal and external wastegate options are available
FeaturesUnparalleled transient responseAggressive aerodynamics with 7+7 splitter wheelsLightweight 310s stainless steel investment cast turbine housingsLightweight, Aluminium compressor coversCFD-driven designed housings for optimal ARs and flowT14 Inconel turbine wheel for extreme EGTsVSR speed balancedProprietary dual ceramic bearing systemIntegrated Iron backplate on center housing
SpecificationsCompressor I”let: 4″ / 101.6mmCompressor Inducer: 62mmTurbine Inlet: V-Ban” (2.25″)Turbine Exducer: 62mmTurbine AR: 0.82Turbine Outlet: V-Ban” (3.00″)Weight: 6.06kg / 13.3lbsHorsepower Rating: 650-800HP
